Multiple Needles
Multiple NeedlesMultiple Needles

Multiple Needles

BI-MN04-08
€126,00

    Boost your productivity using these multiple needles.

    Possibility to select the number of tips.

  • DESCRIPTION
  • DETAILS
  • ASK MORE

multiply one's productivity without long process setup times

Our multiple needles are characterized by the extreme miniaturizationare manufactured entirely in AISI 316 stainless steel and completely assembled with a laser welding process.


Thanks to the manufacturing material, it is possible to spin any type of polymer, even with the most corrosive solvents at high temperatures.

🟢WHAT ADVANTAGES DO YOU GET FROM USING THIS multiple needle?

The absence of any hydraulic seals makes these needles very compact, sturdy and easy to use. Thanks to a basic geometry, the multiple needles inserted in the electrospinning process behave exactly like a single needle, therefore making it possible

to leave all the process parameters set for a single needle unchanged and only multiply the flow rate for the number of needles used.


The system features a single Luer connection, exactly like the classic single needles, from which 4, 6 or 14 identical tips come out thus making it possible to multiply one's productivity without requiring long process setup times.


tips size

  • Tips number: 4, 6 or 14.
  • Tips Length: 15 mm.
  • Tips distance: 6 mm.
  • Tips OD: 0.8 mm.
  • Manifold OD: 3 mm.
  • High voltage connections: n° 2 M3 male.

Attention: Multiple jets require high power from your high voltage power supply- Always check the output current to prevent overload.

Tips size

compatibilities

The sealed multiple needles can be integrated with the Starter Kit, the RT Collector and with the RT Advanced.
