Modular Support Plate – PVC, Dielectric, M6 Grid

PVC plates with precision perforations to fasten needle supports and vertical supports for flat collectors — the most widely used support thanks to its excellent quality/price ratio.

WORKSPACE WITH REPRODUCIBLE GEOMETRIES

These PVC plates permit the simple fastening of both needle supports and vertical supports for flat collectors. They are the most widely used supports due to their good quality/price ratio and are an ideal dielectric solution for most applications.

All components are interchangeable and can be connected together to create support structures for cameras, pumps, lamps and customized collectors.

SPECIFICATIONS

• Material: PVC, dielectric
• Thickness: 15 mm · Hole grid: 25 × 25 mm, M6
• Sizes: from 200×200 mm to 300×600 mm

FREQUENTLY ASKED QUESTIONS

PVC, aluminum or PTFE: which should I choose?

PVC is the cost-effective dielectric option for standard applications. Choose PTFE for the most aggressive solvents, or aluminum when you need electrical conductivity and maximum rigidity.

How do I fasten components to the plate?

With M6 hexagonal socket head screws — available as a 10-piece stainless steel pack.
